Sliding-Door Guide Profile 8 40x10 (cut)
STFP8-40x10-Z
Material: Aluminium, EN AW 6063 T66
Surface: anodized, A6, C0
Color: natural color
A = 2.48 cm2
Cut max.: 3000 mm
Saw Cut Type A
m = 0.74 kg/m
Surface: anodized, A6, C0
Color: natural color
A = 2.48 cm2
Cut max.: 3000 mm
Saw Cut Type A
m = 0.74 kg/m
The sliding-door guide profile 8 40x10 is perfectly for the use of smooth-running sliding doors in frame constructions or racks made of series 8 profiles. The guide profile is attached to series 8 profile grooves using the separately orderable Clip 8 St, galvanized. The sliding door guide profile forms the basis for guiding up to two door leaves made of Clamp profile 8 32x18. The sliding doors are fitted with Corner-Fastening Sets for Clamp-Profile 8 32x18 and Roller set for Corner-Fastener 8 32x18. A total gap of 4.5 mm must be provided for installing the sliding doors.
