C-Rail, Slide Profile 8 (3 meters)
CS-SCHLI-8-S3
Material: Aluminium, EN AW 6063 T66
Surface: anodized, A6, C0
Color: natural color
A = 9.81 cm2, Wx = 7.62 cm3, Wy = 6.71 cm3, Ix = 41.9 cm4, Iy = 16.09 cm4, It = 3.36 cm4
Length: 3000 mm
m = 2.65 kg/m
Surface: anodized, A6, C0
Color: natural color
A = 9.81 cm2, Wx = 7.62 cm3, Wy = 6.71 cm3, Ix = 41.9 cm4, Iy = 16.09 cm4, It = 3.36 cm4
Length: 3000 mm
m = 2.65 kg/m
C-rail, slide profiles 8 are used as base body for self-assembly of C-rail, bearing units. Depending on the type of application and load, you can choose between three different bearing sets. Holes for the four-hole nut and countersinks for the fastening screws must be drilled to secure the bearing sets. The position of the holes is marked by a scribed line in the slide profiles. In general, C-rail systems are variable and safe track roller guides and are designed in particular for the assembly of lifting and sliding doors.
