Profile 8 80x80 heavy (6 meters)
P8-80x80-S-S6
Material: Aluminium, EN AW 6063 T66
Surface: anodized, A6, C0
Color: natural color
max. tensile load groove flanks: 5000 N
A = 26.66 cm2, Wx = 46.89 cm3, Wy = 46.89 cm3, Ix = 187.65 cm4, Iy = 187.65 cm4, It = 139.98 cm4
Length: 6000 mm
m = 7.234 kg/m
Surface: anodized, A6, C0
Color: natural color
max. tensile load groove flanks: 5000 N
A = 26.66 cm2, Wx = 46.89 cm3, Wy = 46.89 cm3, Ix = 187.65 cm4, Iy = 187.65 cm4, It = 139.98 cm4
Length: 6000 mm
m = 7.234 kg/m
Series 8 is suitable for all types of constructions and applications. Different profile types and sizes help to optimally manage the use of materials. The T-slots are designed for screws sized M3 to M8. Also for series 8 the focus is on functionality of modular design principle.
