Profile 8 80x40 3N90 E (3 meters)
P8-80x40-3N90-E-S3
Material: Aluminium, EN AW 6063 T66
Surface: anodized, A6, C0
Color: natural color
max. tensile load groove flanks: 1750 N
A = 8.24 cm2, Wx = 7.5 cm3, Wy = 13.38 cm3, Ix = 15.32 cm4, Iy = 54.68 cm4, It = 16.53 cm4
Length: 3000 mm
m = 2.29 kg/m
Surface: anodized, A6, C0
Color: natural color
max. tensile load groove flanks: 1750 N
A = 8.24 cm2, Wx = 7.5 cm3, Wy = 13.38 cm3, Ix = 15.32 cm4, Iy = 54.68 cm4, It = 16.53 cm4
Length: 3000 mm
m = 2.29 kg/m
Series 8 is suitable for all types of constructions and applications. Different profile types and sizes help to optimally manage the use of materials. The T-slots are designed for screws sized M3 to M8. Also for series 8 the focus is on functionality of modular design principle.
