Profile 5 80x20 (6 meters)
P5-80x20-S6
Material: Aluminium, EN AW 6063 T66
Surface: anodized, A6, C0
Color: natural color
max. tensile load groove flanks: 500 N
A = 6.19 cm2, Wx = 2.71 cm3, Wy = 9.01 cm3, Ix = 2.71 cm4, Iy = 36.07 cm4, It = 2.38 cm4
Length: 6000 mm
m = 1.67 kg/m
Surface: anodized, A6, C0
Color: natural color
max. tensile load groove flanks: 500 N
A = 6.19 cm2, Wx = 2.71 cm3, Wy = 9.01 cm3, Ix = 2.71 cm4, Iy = 36.07 cm4, It = 2.38 cm4
Length: 6000 mm
m = 1.67 kg/m
The small structure of profile 5 makes them especially suitable for smaller and weight-optimized applications. The T-slots are designed for screws sized M3 to M5. Also for series 5 the focus is on functionality of modular design principle.
