Door lock
FV-8
Consists of:
Cylinder lock, equal locking
Lock housing, GD-Zn, black
Lock box, GD-Zn, black
4 Flange nuts M6, St, galvanized
2 Keys
m = 581.0 g
Cylinder lock, equal locking
Lock housing, GD-Zn, black
Lock box, GD-Zn, black
4 Flange nuts M6, St, galvanized
2 Keys
m = 581.0 g
The door lock is a solid lock system that is mounted on door frames and cases. An integrated lock enables the locking of the lock latch. A door gap of 1.5-12.0 mm must be provided for installation. Two fixing holes at a distance of 56,0 mm are required for fixing to the profile groove. The door lock is screwed from the rear. The door lock can be combined with profiles of series 6 and 8. Different closing locks can be ordered on request.
