Magnetic door stop 8, black
MA8
Consists of:
Housing, PA-GF, black
Insert plate, GD-Zn, bright
Stop plate, St, galvanized
2 Countersunk screws DIN 7991, M5x14, galvanized
Compensation insert, PA-GF, black
Load: Holding power F = 30 N
m = 53.0 g
Housing, PA-GF, black
Insert plate, GD-Zn, bright
Stop plate, St, galvanized
2 Countersunk screws DIN 7991, M5x14, galvanized
Compensation insert, PA-GF, black
Load: Holding power F = 30 N
m = 53.0 g
The magnetic stop 8 is used to limit and hold swing doors in place. As soon as a door comes in contact with the stop bracket, it is stopped and held in place by an integrated holding magnet. The holding force per magnetic door stop amounts 30 N.
A door gap of 6.0 mm must be provided for installation. The component is designed for series 8. Suitable fixing screws are included.
A door gap of 6.0 mm must be provided for installation. The component is designed for series 8. Suitable fixing screws are included.
