Hinge 8 Al PP4 light
SCH8-AL-PP4
Consists of:
2 Hinge halves for hinge 8 Al PP4 light, natural anodized
2 Caps, PA-GF, grey
Hinge pin, stainless steel
2 T-slot nuts NS8-M6-with guiding ridge, St, galvanized
2 Countersunk screws M6x14, St, galvanized
m = 113.0 g
2 Hinge halves for hinge 8 Al PP4 light, natural anodized
2 Caps, PA-GF, grey
Hinge pin, stainless steel
2 T-slot nuts NS8-M6-with guiding ridge, St, galvanized
2 Countersunk screws M6x14, St, galvanized
m = 113.0 g
The hinge 8 Al PP4 light is suitable for swing doors and flaps with medium loads. The hinges can be fitted both as top-mounted hinges and in the door gap (between door and frame). A gap of 4.0 mm must be provided on the hinge. Mounting in the door gap offers the advantage that the fixing screws are covered when the door is closed and cannot be removed.
