Multiblock 8 PA, M6 with safety mounting, black
MB8-PA-M6-SB
Consists of:
Multiblock 8 PA, M6, PA-GF, black
Fastening screw M6x22 St, galvanized
Square nut DIN 557-M6, St, galvanized
Captive washer M6 PA-GF, black
Load: Fmax = 250 N
m = 20.5 g
Multiblock 8 PA, M6, PA-GF, black
Fastening screw M6x22 St, galvanized
Square nut DIN 557-M6, St, galvanized
Captive washer M6 PA-GF, black
Load: Fmax = 250 N
m = 20.5 g
The Multiblock 8 PA with safety mounting is a surface mounting according to the regulations of the Machinery Directive 2006/42/EC. The safety mounting and the panel element form an inseparable unit after installation. After loosening the screw connection, the fastening screw remains securely in the hole of the panel element due to the captive washer. The Multiblock is suitable for a surface thickness of 3 to 8 mm.
