Panel clamp 8
Z8-PA
Consists of:
2 Housing halves, PA-GF, black
Cap screw DIN912-M6x20, St, galvanized
Hexagon nut DIN934-M6, St, galvanized
2 Spacers, NBR, black
Load: Fmax = 100 N
m = 52.0 g
2 Housing halves, PA-GF, black
Cap screw DIN912-M6x20, St, galvanized
Hexagon nut DIN934-M6, St, galvanized
2 Spacers, NBR, black
Load: Fmax = 100 N
m = 52.0 g
With the panel clamp panel elements from 2 - 10 mm thickness can be attached to the profile without additional processing. By tightening the clamping screws the panel clamp and the panel element are fixed. This type of fixing is particularly suitable for frameless panes.
