Fastener D30-45° Al

WV-D30-45-AL
Consists of:
2 Connector halves, GD-Al, bright
Cap screw DIN 912, M6x28, St, galvanized
Hexagon nut DIN 985 (self-locking), St, galvanized
m = 95.0 g
The fastener D30-45° Al enables easy assembly of support struts at an angle of 45°. Additional profiles for stiffening of structures can be mounted quickly and easily with this fastener. The intended immersion depth of the profile tube in the fastener is 25 mm. The pre-assembled fastener s clamped from the outside with a cap screw M6 (AF5). By tightening the fastening screw, a permanent hold is ensured by positive locking on the profile tubes. The tightening torque of the fastening screw is M = 10 Nm. If required the screw points can be closed with additionally orderable Cap D30 arched R15, grey.
