Transverse fastener D30 Al
KRV-D30-AL
Consists of:
2 Cross connector halves, GD-Al, bright
Cap screw DIN 912, M6x28, St, galvanized
Hexagon nut DIN 985 (self-locking), St, galvanized
m = 66.5 g
2 Cross connector halves, GD-Al, bright
Cap screw DIN 912, M6x28, St, galvanized
Hexagon nut DIN 985 (self-locking), St, galvanized
m = 66.5 g
The transverse fastener D30 Al enables to mount two at an angle of 90° crossing profile tubes D30. Additional profiles for stiffening of structures can be mounted quickly and easily with this fastener. The pre-assembled transverse fastener is clamped from the outside with a cap screw M6 (AF5). By tightening the fastening screw, a permanent hold is ensured by positive locking on the profile tubes. The tightening torque of the fastening screws is M = 10 Nm. The maximum tensile load is Fmax = 500 N. If required the screw points can be closed with additionally orderable Cap D30 arched R15, grey.
