Würfelverbinder 8 40 - 3D
  • Würfelverbinder 8 40 - 3D
  • Würfelverbinder 8 40 - 3D

Cube connector 8 40 - 3D

WUEV8-40-3D
Material: GD-Zn
Surface: painted
Color: white aluminum
m = 103.0 g

Cube connectors 3D allow up to three profiles to be screwed together for corner connections. They are particularly suitable for showcases, cover hoods and lightweight constructions. The aluminum-colored design of the base body and the included caps lends a particularly elegant appearance. In order to achieve fatigue strength, safety paint should be used for the fastening screws. For fastening three countersunk screws M8x20 as well as one M8x25 thread each in the core hole are required. Cube connectors cannot be used in combination with closed grooves.
