Automatic-fastening set 12, galvanized
SS-VE12
Consists of:
Cutting sleeve 12 St
Cap screw M8x60
T-slot nut 12 St M8 with guiding ridge
(without cap)
Material: St
Surface: galvanized
M = 34 Nm
m = 135.5 g
Cutting sleeve 12 St
Cap screw M8x60
T-slot nut 12 St M8 with guiding ridge
(without cap)
Material: St
Surface: galvanized
M = 34 Nm
m = 135.5 g
Automatic-fastening set 12, galvanized are friction-locked connectors with the possibility of retrofitting and moving series 12 profiles. No additional profile machining is required to install the connector. The connector sleeve is screwed into a profile groove counterclockwise on the face side. The thread is self-tapping. A bit insert with width across flats AF6 is required to screw in the sleeve. It is recommended to use automatic-fastening screws in pairs.
