Conduit profile U 40x40 (cut)
KP-U-40x40-E-Z
Material: Aluminum, EN AW 6063 T66
Surface: anodized, A6, C0
Color: natural color
A = 1.7 cm2
Cut max.: 3000 mm
Saw Cut Type B
m = 0.46 kg/m
Surface: anodized, A6, C0
Color: natural color
A = 1.7 cm2
Cut max.: 3000 mm
Saw Cut Type B
m = 0.46 kg/m
Conduit profiles of the E variant are suitable for the construction of installation ducts and for laying cables and hoses. The U-shaped aluminum profiles have fixed side walls. Furthermore, they have a high inherent stability and offer a visually appealing design. Mounting a cover profile creates two screw channels for fixing and attaching trunking cover caps. By using a suitable cover cap, the associated lid profiles of variant E are secured against accidental opening. Recommended screws for fastening the cover caps in grid dimension 40: tapping screw DIN 7981 St 4.2x9.5, galvanized. The use of a self-tapping screw also ensures an electrically conductive connection.
