Clamp profile-connector 8 40x40 E
KPV-40x40-E
Consists of:
Clamp profile-connector, GD-Zn, white aluminum painted
2 Cap screws DIN912, M8x20, St, galvanized
m = 203.0 g
Clamp profile-connector, GD-Zn, white aluminum painted
2 Cap screws DIN912, M8x20, St, galvanized
m = 203.0 g
Clamp profile connectors 8 40x40 E are used for easy assembly of profile frames, especially for frame elements for the construction of protective fences for example. The connector is suitable for both clamping profiles and standard series 8 profiles. Due to integrated free spaces in the connector, it is not necessary to notch surfaces that are inserted into profile grooves. For assembly, a threaded hole M8x18 must be drilled into the core hole of the frame profiles.
