C-Rail, Rail Profile 8 (3 meters)
CS-SCHIP-8-S3
Material: Aluminium, EN AW 6063 T66
Surface: anodized, A6, C0
Color: natural color
A = 11.41 cm2, Wx = 14.34 cm3, Wy = 6.99 cm3, Ix = 84.49 cm4, Iy = 16.61 cm4, It = 2.41 cm4
Length: 3000 mm
m = 3.10 kg/m
Surface: anodized, A6, C0
Color: natural color
A = 11.41 cm2, Wx = 14.34 cm3, Wy = 6.99 cm3, Ix = 84.49 cm4, Iy = 16.61 cm4, It = 2.41 cm4
Length: 3000 mm
m = 3.10 kg/m
C-rail, rail profiles 8 are used as running rails of C-rail guidance systems. Both the bearing units 8 K (without shafts) and the variants 1R and 3R (with shafts D14) can be used in the series 8 rail profiles. In general, C-rail systems are variable and safe track roller guides and are designed in particular for the assembly of lifting and sliding doors.
