Foot Mounting Bracket 8 D80xM16, aluminum white, painted
SFS8-D80-M16
Consists of:
Foot mounting bracket 8 D80xM16, GD-Al, aluminum white, painted
2 Fixings, GD-Zn, galvanized
Load: Fmax = 4000 N
m = 384.0 g
Foot mounting bracket 8 D80xM16, GD-Al, aluminum white, painted
2 Fixings, GD-Zn, galvanized
Load: Fmax = 4000 N
m = 384.0 g
The foot mounting bracket 8 D80-M16 enables racks to be set up and leveled at a short distance from the floor. The foot mounting bracket is mounted on the side of a frame construction and thus enables a low center of gravity. The base is designed for M16 threaded spindles. The scope of delivery includes two groove fixings for profile groove 8. For fastening separately orderable cap screws and washers of size M8 are recommended.
