Profile 8 80x40 4N180 E (6 meters)
P8-80x40-4N180-E-S6
Material: Aluminium, EN AW 6063 T66
Surface: anodized, A6, C0
Color: natural color
max. tensile load groove flanks: 1750 N
A = 8.04 cm2, Wx = 7.56 cm3, Wy = 13.85 cm3, Ix = 15.12 cm4, Iy = 55.41 cm4, It = 21.9 cm4
Length: 6000 mm
m = 2.23 kg/m
Surface: anodized, A6, C0
Color: natural color
max. tensile load groove flanks: 1750 N
A = 8.04 cm2, Wx = 7.56 cm3, Wy = 13.85 cm3, Ix = 15.12 cm4, Iy = 55.41 cm4, It = 21.9 cm4
Length: 6000 mm
m = 2.23 kg/m
Series 8 is suitable for all types of constructions and applications. Different profile types and sizes help to optimally manage the use of materials. The T-slots are designed for screws sized M3 to M8. Also for series 8 the focus is on functionality of modular design principle.
