New

Schwenkwinkel 130, verzinkt

Pivot angle 130, galvanized

Order number: SCHW-130

Material: St
Surface: galvanized
m = 221.0 g

Description
Attachments

Pivot angles are used for a connection between two hinges with an adjustable angle. It can be attached using a clamp lever. Pivot angles are especially well-suited for incline adjustments of table elements.

Download Product PDF

Download "SCHW-130.stp" (36.24KB)
