Standard-fastener 8, galvanized
ZP8
Material: St
Surface: galvanized
M = 25 Nm
m = 11.0 g
Surface: galvanized
M = 25 Nm
m = 11.0 g
Standard-fasteners enable heavy-duty, right-angled and friction-locked connections. The standard fastener ensures a optimum force transmission and secures the connection against twisting. For assembly a supply hole D = 7.0 mm and a tapped hole M8 in the core hole are required. The drilling dimension for the required hole is 20.0 mm from the outside of the profile edge.
