Wellengitter Al 3 mm 30x30, blank (Zuschnitt)
  • Wellengitter Al 3 mm 30x30, blank (Zuschnitt)

Corrugated mesh Al 3 mm 30x30, bright (cut)

FE-WG-AL3-30x30-Z
Wire thickness: 3.0 mm
Mesh size: 30 mm
Material: Al
Surface: bright
Cut max.: 2970 x 1780 mm
Cut: DL-S-FE-G
m = 1.60 kg/m2

Corrugated mesh Al, bright are suitable for partitions and protective cladding. They are often used in combination with clamping profiles. If the use of a mesh is planned in combination with a standard series 8 profile, clamp blocks 8 for corrugated mesh and clamping springs 8 can be used for securing. Minimum width of one blank: 150 mm. Note: Double the wire thickness should be used as installation dimension (thickness).
