Sliding-door guide set 8/8, black
SFS-8/8
Consists of:
4 Sliders (2 x right, 2 x left), POM, black
Spring pin, St, galvanized
Spring, St, stainless steel
m = 45.5 g
4 Sliders (2 x right, 2 x left), POM, black
Spring pin, St, galvanized
Spring, St, stainless steel
m = 45.5 g
The sliding-door guide set 8/8 is used to construct sliding doors in combination with the clamping profile 8 32x18. One guide set is required per door. Fastening is achieved by engaging the spring bolt in the Ø 7 mm mounting hole of the clamping profile connection set 8 32x18. For constructions with door elements of the same size, the following formula applies to the profile length: l = (L+32x(n-1)-8)/n. The 4 mm lateral projection of the cover caps is included. The maximum weight of the doors is 10 kg.
