C-Rail, Bearing Unit 8 D14 1R
CS-LE-8D14-1R
Consists of:
C-rail, slide profile 8, Al, anodized
C-rail, slide profile cap set 8, PA-GF, black
C-rail, bearing set 8 D14 1R
Load: Fmax = 750 N
m = 579.5 g
C-rail, slide profile 8, Al, anodized
C-rail, slide profile cap set 8, PA-GF, black
C-rail, bearing set 8 D14 1R
Load: Fmax = 750 N
m = 579.5 g
The C-rail, bearing unit 8 D14 1R is used as a bearing unit for the self-assembly of C-rail systems. The pre-assembled units are equipped with wiper and lubrication systems as well as cover caps. The track roller used is durable and maintenance-free. In general, C-rail systems are variable and safe track roller guides and are especially designed for the construction of lifting and sliding doors. The C-rail, bearing unit 8 D14 1R can be subjected to a maximum tensile load of Fmax = 750 N. To ensure that the bearing unit is secured against tilting, the use of two ground guide shafts D14 is recommended.
