Stellfuß 8 240x160, schwarz
  • Stellfuß 8 240x160, schwarz
  • Stellfuß 8 240x160, schwarz

Stand foot 8 240x160, black

SF-8-240x160-SCH
Material: St
Surface: powder coated
Color: black
m = 1.063 kg
The stand foot 8 240x160, black enables robust and cost-effective floor mounting. The stand foot is designed for free-standing protective and partition walls. With this variant, uneven floors can be compensated for up to 20 mm (using a hexagonal screw M8x30) and the inclination of upright profiles can be adjusted by +/- 5°. The stand foot can be anchored to the floor with floor-fastening sets M12x145, galvanized that can be ordered separately. Button-head screws M8x16, galvanized and T-slot nuts 8 St M8, galvanized are recommended for fixing the component to the base structure.



    Technical specifications:
  • Base plate dimensions: 240 mm x 44 mm

  • Height: 160 mm

  • Compatible Series 8 profiles: 40x40 mm, 80x40 mm




    Adjustment options:
  • Inclination adjustment: ±5°, enables flexible adaptation to uneven surfaces

  • Height adjustment: +20 mm, by inserting a hexagon head screw into a core hole in the profile upright








    Advantages:
  • High stability by solid design and large-area floor connection making it suitable for free-standing structures

  • Space-saving design, optimizes the floor storage space

  • Flexible alignment thanks to adjustable inclination and height

  • Easy installation thanks to integrated adjustment features and standardized mounting
